Ubo Pro 4 and 5 - Reservation

Reserve either Ubo Pro 4 or Pro 5 for $10. We will confirm details via email before shipping.

• Ubo Pro 4 - $149
• Ubo Pro 5 - $169

Optional add-ons:

• Ubo HAB PCIe board: $18
• NVMe drive: 128GB $29, 256GB $59
• Quick access cover add-on: $15

Lead time:

We are currently shipping Kickstarter orders which are expected to be fully delivered by mid June 2026 and we will begin fulfilling reservations made here right after based on reservation number.

Assembly Instructions:

https://www.youtube.com/watch?v=TLUX2dLxzPY

Notice

This unit ships as a kit WITHOUT Raspberry Pi and you need to assemble.

For code checkout our GitHub page:

https://github.com/ubopod/ubo_app

Specifications:

• Display: 1.54 inch TFT IPS 240x240 pixels resolution
• Kay pad: 7 buttons on a soft touch silicon keypad
• Microphone: Dual stereo microphones capable of recording 48KHz audio
• Speaker: Stereo speakers, up to 48KHz, <0.1% THD with 1Watt per channel
• Audio Line Out: 40mW output power into 16 Ohm at 3.3V, THD -75dB at 20mW, SNR 90dB with 16 Ohm load; jack insertion detection
• LED ring: 27 individually controllable RGB LEDs (SK6812), NeoPixel compatible
• Camera: 5MP Arducam as default with 16MP Autofocus Arducam as optional upgrade via add-ons. Ubo Pro 4 enclosure supports Arducam 5MP (default) as well as Raspberry Pi official camera module V1, V2. Ubo Pro 5 also support Arducam 16MP and V3.
• Computer: Raspberry Pi 4 or 5
• Thermal: Active and passive thermal management support overclocking up to 2.1GHz without throttling
• Power button: Offers safe shutdown and power-on operations
• Infrared Communications
• IR receiver: AC coupled response from 20 kHz to 60 kHz, all data formats, 5m range
• IR transmitter: 940 nm, omnidirectional, with high radiant power and speed
• Zigbee/Zwave/Lora Radio: optional third-party USB dongle
• Sensors
• Temperature: ±1 °C accuracy over -25 °C to +100 °C range, (PCT2075 by NXP)
• Ambient light: 0 to 120 Kilolux [klx] with resolution down to 0.0036 lx/ct (VEML7700 by Vishay)
• Privacy & Security:
• Crypto chip: OPTIGA TRUST M SLS32AIA by Infineon (solder pad only)
• Physical privacy curtain for camera
• Hardware disconnect switch for microphones
• Dimensions (W x L x H): 5.1 x 3.9 x 2 inches (130 x 99 x 52 mm)
• Weight 0.75 lb (340g)
